Dual-Tank Stainless Steel Fermenter
Specifically designed for process scale-up or mass production.
Multi-stage condition control is achieved through tiered cultivation (seed tank, fermenter/intermediate tank). Tank configurations can be customized according to production scale.
Product Advantage
• Parameter Setting: Supporting adjustment of key fermentation parameters such as temperature, pH, and stirring speed, which can be flexibly adjusted according to specific process requirements.
• Stainless steel material: Made of 304/316L stainless steel, which is corrosion resistant and easy to clean.
• Easy to use: Compact design and user-friendly interface make it easy for users to set up and monitor.
• Optimize the mixing system: Customize the stirring system to improve mixing uniformity.
Product Parameter
|
Model |
RY-BIO-SS |
Tank material |
Body 316L / Jacket 304 |
|
Volume |
15L~100L |
Stirring Way |
Mechanical stirring/magnetic stirring |
|
Loading Ratio |
40-75% |
Driving Way |
Servo Driver / Frequency Converter |
|
Sealing Method |
Mechanical Sealing |
Sterilization Way |
On-site Sterilization |
|
Control System |
PLC+Touchable Screen, Auto-Control During Fermentation Process |
||
|
Basic Configuration |
Temperature, pH, Dissolved Oxygen, Defoaming, Feeding Replenishment, Rotation Speed, Airflow Rate, Sterilization, Tank Pressure, Intake Filtration |
||
|
Optional Configuration |
OD, ORP, Conductivity, Liquid Level Control, Tank Weighing, Feeding Weighing System, Multi-Channel Gas, Multi-Channel Feeding, Exhaust Gas Analysis, Echosmart Software, etc. |
||
Product Service After Sales
One-year quality assurance, life-time maintenance.
If buyer met any problems during using, the seller will provide online service for free.
